(1).xml配置
class="dp-xml" start="1">
- <!-- 配置container和pager的clipChildren=false, 并且指定marginLeft 和 marginRight 的值-->
- <LinearLayout
- android:id="@+id/container"
- android:layout_width="match_parent"
- android:layout_height="100dp"
- android:clipChildren="false"
- android:gravity="center_horizontal"
- android:layerType="software"
- android:orientation="horizontal" >
- <android.support.v4.view.ViewPager
- android:id="@+id/viewpager"
- android:layout_width="match_parent"
- android:layout_height="match_parent"
- android:layout_marginLeft="110dp"
- android:layout_marginRight="110dp"
- android:clipChildren="false" >
- </android.support.v4.view.ViewPager>
- </LinearLayout>
(2).java代码
- // 1.设置幕后item的缓存数目
- viewPager.setOffscreenPageLimit(3);
- // 2.设置页与页之间的间距
- viewPager.setPageMargin(10);
- // 3.将父类的touch事件分发至viewPgaer,否则只能滑动中间的一个view对象
- container.setOnTouchListener(new View.OnTouchListener() {
- @Override
- public boolean onTouch(View v, MotionEvent event) {
- return viewPager.dispatchTouchEvent(event);
- }
- });
- /**
- * MainActivity.java
- *
- * @author http://blog.csdn.net/zimo2013
- *
- */
- public class MainActivity extends Activity implements OnPageChangeListener {
- private ViewPager viewPager;
- private List<View> views = new ArrayList<View>();
- private LinearLayout container;
- private TextView tvTitle;
- private LayoutInflater inflater;
- private String dir;
- @Override
- protected void onCreate(Bundle savedInstanceState) {
- super.onCreate(savedInstanceState);
- setContentView(R.layout.activity_main);
- inflater = getLayoutInflater();
- container = (LinearLayout) findViewById(R.id.container);
- viewPager = (ViewPager) findViewById(R.id.viewpager);
- tvTitle = (TextView) findViewById(R.id.title);
- //这里预先在sdcard准备一些轮播图片资源
- dir = Environment.getExternalStorageDirectory().getAbsolutePath();
- // 得到views集合
- views = new ArrayList<View>();
- //此处可以根据需要自由设定,这里只是简单的测试
- for (int i = 1; i <= 12; i++) {
- View view = inflater.inflate(R.layout.guide_item, null);
- views.add(view);
- }
- /////////////////////主要配置//////////////////////////////////////
- // 1.设置幕后item的缓存数目
- viewPager.setOffscreenPageLimit(3);
- // 2.设置页与页之间的间距
- viewPager.setPageMargin(10);
- // 3.将父类的touch事件分发至viewPgaer,否则只能滑动中间的一个view对象
- container.setOnTouchListener(new View.OnTouchListener() {
- @Override
- public boolean onTouch(View v, MotionEvent event) {
- return viewPager.dispatchTouchEvent(event);
- }
- });
- ////////////////////////////////////////////////////////////////
- viewPager.setAdapter(new MyAdapter()); // 为viewpager设置adapter
- viewPager.setOnPageChangeListener(this);// 设置监听器
- }
- // PagerAdapter是object的子类
- class MyAdapter extends PagerAdapter {
- /**
- * PagerAdapter管理数据大小
- */
- @Override
- public int getCount() {
- return views.size();
- }
- /**
- * 关联key 与 obj是否相等,即是否为同一个对象
- */
- @Override
- public boolean isViewFromObject(View view, Object obj) {
- return view == obj; // key
- }
- /**
- * 销毁当前page的相隔2个及2个以上的item时调用
- */
- @Override
- public void destroyItem(ViewGroup container, int position, Object object) {
- container.removeView((View) object); // 将view 类型 的object熊容器中移除,根据key
- }
- /**
- * 当前的page的前一页和后一页也会被调用,如果还没有调用或者已经调用了destroyItem
- */
- @Override
- public Object instantiateItem(ViewGroup container, int position) {
- System.out.println("pos:" + position);
- View view = views.get(position);
- // 如果访问网络下载图片,此处可以进行异步加载
- ImageView img = (ImageView) view.findViewById(R.id.icon);
- img.setImageBitmap(BitmapFactory.decodeFile(dir + getFile(position)));
- container.addView(view);
- return views.get(position); // 返回该view对象,作为key
- }
- }
- public void onPageScrolled(int position, float positionOffset, int positionOffsetPixels) {
- if (viewPager != null) {
- viewPager.invalidate();
- }
- }
- // 一个新页被调用时执行,仍为原来的page时,该方法不被调用
- public void onPageSelected(int position) {
- tvTitle.setText(getFile(position));
- }
- /*
- * SCROLL_STATE_IDLE: pager处于空闲状态 SCROLL_STATE_DRAGGING: pager处于正在拖拽中
- * SCROLL_STATE_SETTLING: pager正在自动沉降,相当于松手后,pager恢复到一个完整pager的过程
- */
- public void onPageScrollStateChanged(int state) {
- }
- public String getFile(int position) {
- return "/img" + ((position + 1) >= 10 ? (position + 1) : "0" + (position + 1)) + ".png";
- }
- }
- <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
- android:layout_width="match_parent"
- android:layout_height="match_parent"
- android:layout_marginLeft="15dp"
- android:layout_marginRight="15dp"
- android:layout_marginTop="50dp"
- android:orientation="vertical" >
- <View
- android:layout_width="match_parent"
- android:layout_height="2dp"
- android:background="#ffbd2021" />
- <!-- 配置container和pager的clipChildren=false, 并且指定marginLeft 和 marginRight 的值 -->
- <LinearLayout
- android:id="@+id/container"
- android:layout_width="match_parent"
- android:layout_height="100dp"
- android:clipChildren="false"
- android:gravity="center_horizontal"
- android:layerType="software"
- android:orientation="horizontal" >
- <android.support.v4.view.ViewPager
- android:id="@+id/viewpager"
- android:layout_width="match_parent"
- android:layout_height="match_parent"
- android:layout_marginLeft="110dp"
- android:layout_marginRight="110dp"
- android:clipChildren="false" >
- </android.support.v4.view.ViewPager>
- </LinearLayout>
- <View
- android:layout_width="match_parent"
- android:layout_height="2dp"
- android:background="#ffbd2021" />
- <ImageView
- android:layout_width="match_parent"
- android:layout_height="wrap_content"
- android:background="@drawable/line" />
- <TextView
- android:id="@+id/title"
- android:layout_width="match_parent"
- android:layout_height="wrap_content"
- android:layout_gravity="center"
- android:gravity="center_horizontal"
- android:scaleType="fitXY"
- android:src="@drawable/ic_launcher"
- android:text="baidu"
- android:textSize="18sp" />
- </LinearLayout>
