        下面介绍如何在word里面插入图片，顺便小弟发现MSDN官网有完整的OpenXML教程，虽然是全英文的不过还是很有帮助的。

        Tips，原来摘抄代码里面没有模板，在copy过来发现插入word中的图片大小不一样，我们如何查找设置图片大小带代码的那一块，建议自己用在word里面插入一张图片，通过OpenXml Tools 反编译出C#代码，然后改变图片的大小，再次反编译。

使用byeond compare 【http://www.scootersoftware.com/ 下载地址】比较C#代码，就会发现是因为new DW.Extent() { Cx = 990000L, Cy = 792000L}  是因为这段设置照成的。 以后其实很多地方都可以借助OpenXml Tools反编译来进行对比。查看设置样式的属性位置。

        MSDN openxml学习链接:  http://msdn.microsoft.com/en-us/library/office/bb491088(v=office.15).aspx

using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using DocumentFormat.OpenXml;
using DocumentFormat.OpenXml.Packaging;
using DocumentFormat.OpenXml.Wordprocessing;
using System.IO;
using DW = DocumentFormat.OpenXml.Drawing.Wordprocessing;
using PIC = DocumentFormat.OpenXml.Drawing.Pictures;
using A = DocumentFormat.OpenXml.Drawing;

namespace AddPictureIntoWord
{
    public class Program
    {
        public static void Main(string[] args)
        {
            string picPath = "u=639047729,3872612606&fm=11&gp=0.bmp";
            string filePath = "Test.docx";
            AddPictureIntoWord(filePath, picPath);
        }

        public static void AddPictureIntoWord(string filePath, string picturePath)
        {
            using (WordprocessingDocument doc = WordprocessingDocument.Open(filePath, true))
            {
                string picType = picturePath.Split('.').Last();
                ImagePartType imagePartType;
                ImagePart imagePart = null;
                // 通过后缀名判断图片类型, true 表示忽视大小写
                if (Enum.TryParse<ImagePartType>(picType, true, out imagePartType))
                {
                    imagePart = doc.MainDocumentPart.AddImagePart(imagePartType);
                }

                imagePart.FeedData(File.Open(picturePath, FileMode.Open)); // 读取图片二进制流
                AddImageToBody(doc, doc.MainDocumentPart.GetIdOfPart(imagePart));
            }
        }

        // 摘抄自http://msdn.microsoft.com/EN-US/library/office/bb497430(v=office.15).aspx?cs-save-lang=1&cs-lang=csharp#code-snippet-5
      private static void AddImageToBody(WordprocessingDocument wordDoc, string relationshipId)
        {
            // Define the reference of the image.
            var element =
                 new Drawing(
                     new DW.Inline(
                         new DW.Extent() { Cx = 990000L, Cy = 792000L }, // 调节图片大小
                         new DW.EffectExtent()
                         {
                             LeftEdge = 0L,
                             TopEdge = 0L,
                             RightEdge = 0L,
                             BottomEdge = 0L
                         },
                         new DW.DocProperties()
                         {
                             Id = (UInt32Value)1U,
                             Name = "Picture 1"
                         },
                         new DW.NonVisualGraphicFrameDrawingProperties(
                             new A.GraphicFrameLocks() { NoChangeAspect = true }),
                         new A.Graphic(
                             new A.GraphicData(
                                 new PIC.Picture(
                                     new PIC.NonVisualPictureProperties(
                                         new PIC.NonVisualDrawingProperties()
                                         {
                                             Id = (UInt32Value)0U,
                                             Name = "New Bitmap Image.jpg"
                                         },
                                         new PIC.NonVisualPictureDrawingProperties()),
                                     new PIC.BlipFill(
                                         new A.Blip(
                                             new A.BlipExtensionList(
                                                 new A.BlipExtension()
                                                 {
                                                     Uri =
                                                       "{28A0092B-C50C-407E-A947-70E740481C1C}"
                                                 })
                                         )
                                         {
                                             Embed = relationshipId,
                                             CompressionState =
                                             A.BlipCompressionValues.Print
                                         },
                                         new A.Stretch(
                                             new A.FillRectangle())),
                                     new PIC.ShapeProperties(
                                         new A.Transform2D(
                                             new A.Offset() { X = 0L, Y = 0L },
                                             new A.Extents() { Cx = 990000L, Cy = 792000L }), //与上面的对准
                                         new A.PresetGeometry(
                                             new A.AdjustValueList()
                                         ) { Preset = A.ShapeTypeValues.Rectangle }))
                             ) { Uri = "http://schemas.openxmlformats.org/drawingml/2006/picture" })
                     )
                     {
                         DistanceFromTop = (UInt32Value)0U,
                         DistanceFromBottom = (UInt32Value)0U,
                         DistanceFromLeft = (UInt32Value)0U,
                         DistanceFromRight = (UInt32Value)0U,
                         EditId = "50D07946"
                     });

            // Append the reference to body, the element should be in a Run.
            wordDoc.MainDocumentPart.Document.Body.AppendChild(new Paragraph(new Run(element)));
        }

    }
}
