今天将真正去看dubbo内部的实现过程，看dubbo的源码前我先把dubbo的用户指南和开发指指南大概的看了一遍，这样再看dubbo源码比较轻松。从用户指南和开发指指南可以找到相应的切入点，今天将介绍的是dubbo的初始化解析bean的过程:

解析服务
基于dubbo.jar内的META-INF/spring.handlers配置，Spring在遇到dubbo名称空间时，会回调DubboNamespaceHandler。
所有dubbo的标签，都统一用DubboBeanDefinitionParser进行解析，基于一对一属性映射，将XML标签解析为Bean对象。
在ServiceConfig.export()或ReferenceConfig.get()初始化时，将Bean对象转换URL格式，所有Bean属性转成URL的参数。
然后将URL传给Protocol扩展点，基于扩展点的Adaptive机制，根据URL的协议头，进行不同协议的服务暴露或引用。

dubbo服务的暴露调用的是：ServiceConfig.export()代码如下:
com.alibaba.dubbo.config.ServiceConfig#export

//暴露服务
    public synchronized void export() {
        if (provider != null) {
            if (export == null) {
                export = provider.getExport();
            }
            if (delay == null) {
                delay = provider.getDelay();
            }
        }
        if (export != null && ! export.booleanValue()) {
            return;
        }
        if (delay != null && delay > 0) {
            Thread thread = new Thread(new Runnable() {
                public void run() {
                    try {
                        Thread.sleep(delay);
                    } catch (Throwable e) {
                    }
                    doExport();
                }
            });
            thread.setDaemon(true);
            thread.setName("DelayExportServiceThread");
            thread.start();
        } else {
            doExport();
        }
    }

在查看export调用链时，可看到2个地方调用了该方法：
1、com.alibaba.dubbo.config.spring.AnnotationBean#postProcessAfterInitialization：注解的方式暴露时
2、com.alibaba.dubbo.config.spring.ServiceBean#afterPropertiesSet：以spring配置文件暴露时

AnnotationBean类的继承关系
public class AnnotationBean extends AbstractConfig implements DisposableBean, BeanFactoryPostProcessor, BeanPostProcessor, ApplicationContextAware {

AnnotationBean实现了spring bean和context相关的接口，在spring扫描完注解类，并解析完时调用 export()方法对服务进行暴露

ServiceBean
public class ServiceBean<T> extends ServiceConfig<T> implements InitializingBean, DisposableBean, ApplicationContextAware, ApplicationListener, BeanNameAware {
在spring初始化解析bean完成，主要是在对spring标签的解析，bean的定义，bean的属性解析设值等完成后 进行 export()

因为dubbo是自己的自定义标签，所以对于bean的解析是 export 前最重要的部分，今天先不看服务的暴露，先看dubbo对于服务的解析，重要的两个类：
com.alibaba.dubbo.config.spring.schema.DubboNamespaceHandler
com.alibaba.dubbo.config.spring.schema.DubboBeanDefinitionParser#parse

以下为DubboNamespaceHandler代码，加上了我的注释（自己的理解）
public class DubboNamespaceHandler extends NamespaceHandlerSupport {

    static {
        /**
         * 检索是否有重复的命名空间处理器
         */
            Version.checkDuplicate(DubboNamespaceHandler.class);
    }

    public void init() {
        /**
         * 注册bean，真正负解析的是DubboBeanDefinitionParser
         * DubboBeanDefinitionParser将解析所有的属性，并将属性值放入BeanDefinition
         */
        registerBeanDefinitionParser("application", new DubboBeanDefinitionParser(ApplicationConfig.class, true));
        registerBeanDefinitionParser("module", new DubboBeanDefinitionParser(ModuleConfig.class, true));
        registerBeanDefinitionParser("registry", new DubboBeanDefinitionParser(RegistryConfig.class, true));
        registerBeanDefinitionParser("monitor", new DubboBeanDefinitionParser(MonitorConfig.class, true));
        registerBeanDefinitionParser("provider", new DubboBeanDefinitionParser(ProviderConfig.class, true));
        registerBeanDefinitionParser("consumer", new DubboBeanDefinitionParser(ConsumerConfig.class, true));
        registerBeanDefinitionParser("protocol", new DubboBeanDefinitionParser(ProtocolConfig.class, true));
        registerBeanDefinitionParser("service", new DubboBeanDefinitionParser(ServiceBean.class, true));
        registerBeanDefinitionParser("reference", new DubboBeanDefinitionParser(ReferenceBean.class, false));
        registerBeanDefinitionParser("annotation", new DubboBeanDefinitionParser(AnnotationBean.class, true));
    }

}
所有的解析工作都在 DubboBeanDefinitionParser 中

/**
     * 解析dubbo自定义标签,往BeanDefinition设置属性值,这个时候bean还没有创建
     * @param element
     * @param parserContext
     * @param beanClass
     * @param required
     * @return
     */
    @SuppressWarnings("unchecked")
    private static BeanDefinition parse(Element element, ParserContext parserContext, Class<?> beanClass, boolean required) {
        RootBeanDefinition beanDefinition = new RootBeanDefinition();
        beanDefinition.setBeanClass(beanClass);
        //设置懒加载为false，表示立即加载，spring启动时，立刻进行实例化
        //如果设置为true，那么要第一次向容器通过getBean索取bean时实例化，在spring bean的配置里可以配置
        //这里会设置懒加载为false其实还可以得到一个推断就是:dubbo标签创建的bean就是单例bean(singleton bean)
        //因为lazy-init的设置只对singleton bean有效，对原型bean(prototype无效)
        beanDefinition.setLazyInit(false);
        String id = element.getAttribute("id");
        //如果没有设置bean的id
        if ((id == null || id.length() == 0) && required) {
            String generatedBeanName = element.getAttribute("name");
            //name没有配置
            if (generatedBeanName == null || generatedBeanName.length() == 0) {
                //如果是ProtocolConfig类型，bean name默认为 dubbo，其他的为配置的interface值
                if (ProtocolConfig.class.equals(beanClass)) {
                    generatedBeanName = "dubbo";
                } else {
                    generatedBeanName = element.getAttribute("interface");
                }
            }
            /*
             * 如果还为null 那么取 beanClass 的名字，beanClass 其实就是要解析的类型
             * 如：com.alibaba.dubbo.config.ApplicationConfig
             */
            if (generatedBeanName == null || generatedBeanName.length() == 0) {
                generatedBeanName = beanClass.getName();
            }
            //如果id没有设置那么 id = generatedBeanName,如果是ProtocolConfig类型的话自然就是 dubbo
            id = generatedBeanName;
            int counter = 2;
            /*
             * 由于spring的bean id不能重复，但有些标签可能会配置多个如：<dubbo:registry
             * 所以 id 在后面加数字 2、3、4 区分
             */
            while(parserContext.getRegistry().containsBeanDefinition(id)) {
                id = generatedBeanName + (counter ++);
            }
        }
        if (id != null && id.length() > 0) {
            //检查是否有 bean id 相同的
            if (parserContext.getRegistry().containsBeanDefinition(id))  {
                throw new IllegalStateException("Duplicate spring bean id " + id);
            }
            /*
             * 注册 bean 定义
             * org.springframework.beans.factory.support.DefaultListableBeanFactory#registerBeanDefinition
             * 会按照 id 即beanName做一些检查,判断是否重载已加载过的bean等等
             * 跟到代码里其实 bean 的注册也是放到 ConcurrentHashMap 里
             * beanName也就是这里的 id 会放到 list 里
             */
            parserContext.getRegistry().registerBeanDefinition(id, beanDefinition);
            //给bean添加属性值
            beanDefinition.getPropertyValues().addPropertyValue("id", id);
        }
        if (ProtocolConfig.class.equals(beanClass)) {
            for (String name : parserContext.getRegistry().getBeanDefinitionNames()) {
                BeanDefinition definition = parserContext.getRegistry().getBeanDefinition(name);
                PropertyValue property = definition.getPropertyValues().getPropertyValue("protocol");
                if (property != null) {
                    Object value = property.getValue();
                    if (value instanceof ProtocolConfig && id.equals(((ProtocolConfig) value).getName())) {
                        definition.getPropertyValues().addPropertyValue("protocol", new RuntimeBeanReference(id));
                    }
                }
            }
        } else if (ServiceBean.class.equals(beanClass)) { //解析<dubbo:service
            String className = element.getAttribute("class");//获取类全名
            if(className != null && className.length() > 0) {
                RootBeanDefinition classDefinition = new RootBeanDefinition();
                //通过反射获取类
                classDefinition.setBeanClass(ReflectUtils.forName(className));
                classDefinition.setLazyInit(false);
                /*
                    解析子节点，有些配置可能是：
                    <dubbo:service interface="com.alihealth.dubbo.api.drugInfo.service.DemoService"
                         executes="10" >
                        <property  ref="demoService" name="ref"></property>
                        <property  value="1.0.0" name="version"></property>
                     </dubbo:service>
                 */
                parseProperties(element.getChildNodes(), classDefinition);
                /*
                    ref直接设置成了 接口名 + Impl 的bean ？
                    如：com.alihealth.dubbo.api.drugInfo.service.DemoService  + Impl 的bean为啥？
                    那<dubbo:service里定义的 ref 属性有啥用
                 */
                beanDefinition.getPropertyValues().addPropertyValue("ref", new BeanDefinitionHolder(classDefinition, id + "Impl"));
            }
        } else if (ProviderConfig.class.equals(beanClass)) {
            /*
                <dubbo:provider 为缺省配置 ，所以在解析的时候，如果<dubbo:service有些值没配置，那么会用<dubbo:provider值进行填充
             */
            parseNested(element, parserContext, ServiceBean.class, true, "service", "provider", id, beanDefinition);
        } else if (ConsumerConfig.class.equals(beanClass)) {
            /*
             * 同上
             */
            parseNested(element, parserContext, ReferenceBean.class, false, "reference", "consumer", id, beanDefinition);
        }
        Set<String> props = new HashSet<String>();
        ManagedMap parameters = null;
        for (Method setter : beanClass.getMethods()) {
            String name = setter.getName();
            //给model注入值时,如ServiceConfig,方法必须是set开头,并且参数只能为1
            if (name.length() > 3 && name.startsWith("set")
                    && Modifier.isPublic(setter.getModifiers())
                    && setter.getParameterTypes().length == 1) {
                //方法参数类型，因为参数只能是1，所以直接取[0]
                Class<?> type = setter.getParameterTypes()[0];
                //根据set方法名获取属性值，如：setListener 得到的属性为：listener
                String property = StringUtils.camelToSplitName(name.substring(3, 4).toLowerCase() + name.substring(4), "-");
                props.add(property);
                Method getter = null;
                try {
                    getter = beanClass.getMethod("get" + name.substring(3), new Class<?>[0]);
                } catch (NoSuchMethodException e) {
                    try {
                        getter = beanClass.getMethod("is" + name.substring(3), new Class<?>[0]);
                    } catch (NoSuchMethodException e2) {
                    }
                }
                if (getter == null
                        || ! Modifier.isPublic(getter.getModifiers())
                        || ! type.equals(getter.getReturnType())) {
                    continue;
                }

                if ("parameters".equals(property)) {
                    /*
                     * 如果属性为 parameters,如ProtocolConfig里的setParameters(Map<String, String> parameters)
                     * 那么去子节点获取 <dubbo:parameter
                     * <dubbo:protocol name="dubbo" host="127.0.0.1" port="9998" accepts="1000"  >
                         <dubbo:parameter key="adsf" value="adf" />
                         <dubbo:parameter key="errer" value="aerdf" />
                     </dubbo:protocol>
                     */
                    parameters = parseParameters(element.getChildNodes(), beanDefinition);
                } else if ("methods".equals(property)) {
                    /*
                       解析 <dubbo:method 并设置 methods 值 --serviceConfig中
                     */
                    parseMethods(id, element.getChildNodes(), beanDefinition, parserContext);
                } else if ("arguments".equals(property)) {
                    /*
                        同上 ,解析<dubbo:argument --- MethodConfig中
                     */
                    parseArguments(id, element.getChildNodes(), beanDefinition, parserContext);
                } else {
                    String value = element.getAttribute(property);
                    if (value != null) {
                        value = value.trim();
                        if (value.length() > 0) {
                            //不发布到任何注册中心时 registry = "N/A"
                            if ("registry".equals(property) && RegistryConfig.NO_AVAILABLE.equalsIgnoreCase(value)) {
                                RegistryConfig registryConfig = new RegistryConfig();
                                registryConfig.setAddress(RegistryConfig.NO_AVAILABLE);
                                beanDefinition.getPropertyValues().addPropertyValue(property, registryConfig);
                            } else if ("registry".equals(property) && value.indexOf(',') != -1) {
                                //多注册中心用 , 号分隔
                                parseMultiRef("registries", value, beanDefinition, parserContext);
                            } else if ("provider".equals(property) && value.indexOf(',') != -1) {
                                parseMultiRef("providers", value, beanDefinition, parserContext);
                            } else if ("protocol".equals(property) && value.indexOf(',') != -1) {
                                //同上 多协议暴露
                                parseMultiRef("protocols", value, beanDefinition, parserContext);
                            } else {
                                Object reference;
                                if (isPrimitive(type)) {//如果参数类型为 java 的基本类型
                                    if ("async".equals(property) && "false".equals(value)
                                            || "timeout".equals(property) && "0".equals(value)
                                            || "delay".equals(property) && "0".equals(value)
                                            || "version".equals(property) && "0.0.0".equals(value)
                                            || "stat".equals(property) && "-1".equals(value)
                                            || "reliable".equals(property) && "false".equals(value)) {
                                      /*
                                        兼容旧版本xsd中的default值,以上配置的值在xsd中有配置defalt值
                                        <xsd:attribute name="version" type="xsd:string" use="optional" default="0.0.0">
                                      */
                                        value = null;
                                    }
                                    reference = value;
                                } else if ("protocol".equals(property)
                                        //如果属性为 protocol 那么要判断protocol对应的拓展点配置有没有
                                        && ExtensionLoader.getExtensionLoader(Protocol.class).hasExtension(value)
                                        //检查当前使用的协议是否已经解析过 可能在这里被解析过<dubbo:protocol name="dubbo"
                                        && (! parserContext.getRegistry().containsBeanDefinition(value)
                                                || ! ProtocolConfig.class.getName().equals(parserContext.getRegistry().getBeanDefinition(value).getBeanClassName()))) {
                                    if ("dubbo:provider".equals(element.getTagName())) {
                                        logger.warn("Recommended replace <dubbo:provider protocol=\"" + value + "\" ... /> to <dubbo:protocol name=\"" + value + "\" ... />");
                                    }
                                    // 兼容旧版本配置
                                    ProtocolConfig protocol = new ProtocolConfig();
                                    protocol.setName(value);
                                    reference = protocol;
                                } else if ("monitor".equals(property)
                                        //同上
                                        && (! parserContext.getRegistry().containsBeanDefinition(value)
                                                || ! MonitorConfig.class.getName().equals(parserContext.getRegistry().getBeanDefinition(value).getBeanClassName()))) {
                                    // 兼容旧版本配置
                                    reference = convertMonitor(value);
                                } else if ("onreturn".equals(property)) {
                                    //回调方法 类似onSuccess
                                    int index = value.lastIndexOf(".");
                                    // bean的名字
                                    String returnRef = value.substring(0, index);
                                    String returnMethod = value.substring(index + 1);
                                    reference = new RuntimeBeanReference(returnRef);
                                    beanDefinition.getPropertyValues().addPropertyValue("onreturnMethod", returnMethod);
                                } else if ("onthrow".equals(property)) {
                                    //回调 异常执行的方法 ,类似 onError
                                    int index = value.lastIndexOf(".");
                                    String throwRef = value.substring(0, index);
                                    String throwMethod = value.substring(index + 1);
                                    reference = new RuntimeBeanReference(throwRef);
                                    beanDefinition.getPropertyValues().addPropertyValue("onthrowMethod", throwMethod);
                                } else {
                                    if ("ref".equals(property) && parserContext.getRegistry().containsBeanDefinition(value)) {
                                        BeanDefinition refBean = parserContext.getRegistry().getBeanDefinition(value);
                                        /*
                                            必须是单例bean(singleton),原型bean（prototype）不行,sevice初始化一次,在spring容器里也只有一个 实例
                                            是不是和dubbo的幂等有关，如果为原型bean，那么服务就变成有状态的了
                                         */
                                        if (! refBean.isSingleton()) {
                                            throw new IllegalStateException("The exported service ref " + value + " must be singleton! Please set the " + value + " bean scope to singleton, eg: <bean id=\"" + value+ "\" scope=\"singleton\" ...>");
                                        }
                                    }
                                    reference = new RuntimeBeanReference(value);
                                }
                                /*
                                    设置属性，值为另外一个关联的bean
                                    RuntimeBeanReference 固定占位符类，当在beanfactory中作为另外一个bean的引用时，作为属性值对象，将在运行时进行解析
                                 */
                                beanDefinition.getPropertyValues().addPropertyValue(property, reference);
                            }
                        }
                    }
                }
            }
        }
        NamedNodeMap attributes = element.getAttributes();
        int len = attributes.getLength();
        for (int i = 0; i < len; i++) {
            Node node = attributes.item(i);
            String name = node.getLocalName();
            //经过上面的解析,如果还有一些属性没有解析到的
            if (! props.contains(name)) {
                if (parameters == null) {
                    parameters = new ManagedMap();
                }
                String value = node.getNodeValue();
                parameters.put(name, new TypedStringValue(value, String.class));
            }
        }
        if (parameters != null) {
            beanDefinition.getPropertyValues().addPropertyValue("parameters", parameters);
        }
        return beanDefinition;
    }

    private static final Pattern GROUP_AND_VERION = Pattern.compile("^[\\-.0-9_a-zA-Z]+(\\:[\\-.0-9_a-zA-Z]+)?$");

    protected static MonitorConfig convertMonitor(String monitor) {
        if (monitor == null || monitor.length() == 0) {
            return null;
        }
        if (GROUP_AND_VERION.matcher(monitor).matches()) {
            String group;
            String version;
            int i = monitor.indexOf(':');
            if (i > 0) {
                group = monitor.substring(0, i);
                version = monitor.substring(i + 1);
            } else {
                group = monitor;
                version = null;
            }
            MonitorConfig monitorConfig = new MonitorConfig();
            monitorConfig.setGroup(group);
            monitorConfig.setVersion(version);
            return monitorConfig;
        }
        return null;
    }

    private static boolean isPrimitive(Class<?> cls) {
        return cls.isPrimitive() || cls == Boolean.class || cls == Byte.class
                || cls == Character.class || cls == Short.class || cls == Integer.class
                || cls == Long.class || cls == Float.class || cls == Double.class
                || cls == String.class || cls == Date.class || cls == Class.class;
    }

    @SuppressWarnings("unchecked")
    private static void parseMultiRef(String property, String value, RootBeanDefinition beanDefinition,
            ParserContext parserContext) {
        //解析 registries 、providers、protocols 时支持多引用
        String[] values = value.split("\\s*[,]+\\s*");
        ManagedList list = null;
        for (int i = 0; i < values.length; i++) {
            String v = values[i];
            if (v != null && v.length() > 0) {
                if (list == null) {
                    list = new ManagedList();
                }
                list.add(new RuntimeBeanReference(v));
            }
        }
        beanDefinition.getPropertyValues().addPropertyValue(property, list);
    }

    private static void parseNested(Element element, ParserContext parserContext, Class<?> beanClass,
                                    boolean required, String tag, String property, String ref, BeanDefinition beanDefinition) {
        NodeList nodeList = element.getChildNodes();
        if (nodeList != null && nodeList.getLength() > 0) {
            boolean first = true;
            for (int i = 0; i < nodeList.getLength(); i++) {
                Node node = nodeList.item(i);
                if (node instanceof Element) {
                    if (tag.equals(node.getNodeName())
                            || tag.equals(node.getLocalName())) {
                        if (first) {
                            first = false;
                            String isDefault = element.getAttribute("default");
                            /*
                                如果 <dubbo:provider 标签没有配置default开关,那么直接设置 default = "false"
                                这样做的目的是为了让 <dubbo:provider里的配置都只是 <dubbo:service 或 <dubbo:reference的默认或缺省配置
                             */
                            if (isDefault == null || isDefault.length() == 0) {
                                beanDefinition.getPropertyValues().addPropertyValue("default", "false");
                            }
                        }
                        BeanDefinition subDefinition = parse((Element) node, parserContext, beanClass, required);
                        if (subDefinition != null && ref != null && ref.length() > 0) {
                            subDefinition.getPropertyValues().addPropertyValue(property, new RuntimeBeanReference(ref));
                        }
                    }
                }
            }
        }
    }

    private static void parseProperties(NodeList nodeList, RootBeanDefinition beanDefinition) {
        if (nodeList != null && nodeList.getLength() > 0) {
            for (int i = 0; i < nodeList.getLength(); i++) {
                Node node = nodeList.item(i);
                if (node instanceof Element) {
                    //如果是 <property 元素
                    if ("property".equals(node.getNodeName())
                            || "property".equals(node.getLocalName())) {
                        String name = ((Element) node).getAttribute("name");
                        if (name != null && name.length() > 0) {
                            String value = ((Element) node).getAttribute("value");
                            //获取 ref
                            String ref = ((Element) node).getAttribute("ref");
                            if (value != null && value.length() > 0) {
                                beanDefinition.getPropertyValues().addPropertyValue(name, value);
                            } else if (ref != null && ref.length() > 0) {
                                beanDefinition.getPropertyValues().addPropertyValue(name, new RuntimeBeanReference(ref));
                            } else {
                                /*
                                    只支持两种property的设置方法:
                                    <property  ref="" name="">
                                    <property  value="" name="">
                                 */
                                throw new UnsupportedOperationException("Unsupported <property name=\"" + name + "\"> sub tag, Only supported <property name=\"" + name + "\" ref=\"...\" /> or <property name=\"" + name + "\" value=\"...\" />");
                            }
                        }
                    }
                }
            }
        }
    }

    @SuppressWarnings("unchecked")
    private static ManagedMap parseParameters(NodeList nodeList, RootBeanDefinition beanDefinition) {
        if (nodeList != null && nodeList.getLength() > 0) {
            ManagedMap parameters = null;
            for (int i = 0; i < nodeList.getLength(); i++) {
                Node node = nodeList.item(i);
                if (node instanceof Element) {
                    //解析 <dubbo:parameter
                    if ("parameter".equals(node.getNodeName())
                            || "parameter".equals(node.getLocalName())) {
                        if (parameters == null) {
                            parameters = new ManagedMap();
                        }
                        String key = ((Element) node).getAttribute("key");
                        String value = ((Element) node).getAttribute("value");
                        boolean hide = "true".equals(((Element) node).getAttribute("hide"));
                        if (hide) {
                            key = Constants.HIDE_KEY_PREFIX + key;
                        }
                        //添加参数，String 类型
                        parameters.put(key, new TypedStringValue(value, String.class));
                    }
                }
            }
            return parameters;
        }
        return null;
    }

    @SuppressWarnings("unchecked")
    private static void parseMethods(String id, NodeList nodeList, RootBeanDefinition beanDefinition,
                              ParserContext parserContext) {
        if (nodeList != null && nodeList.getLength() > 0) {
            ManagedList methods = null;
            for (int i = 0; i < nodeList.getLength(); i++) {
                Node node = nodeList.item(i);
                if (node instanceof Element) {
                    Element element = (Element) node;
                    //<dubbo:method
                    if ("method".equals(node.getNodeName()) || "method".equals(node.getLocalName())) {
                        String methodName = element.getAttribute("name");
                        if (methodName == null || methodName.length() == 0) {
                            throw new IllegalStateException("<dubbo:method> name attribute == null");
                        }
                        if (methods == null) {
                            methods = new ManagedList();
                        }
                        //解析 <dubbo:method MethodConfig
                        BeanDefinition methodBeanDefinition = parse(((Element) node),
                                parserContext, MethodConfig.class, false);
                        String name = id + "." + methodName;
                        BeanDefinitionHolder methodBeanDefinitionHolder = new BeanDefinitionHolder(
                                methodBeanDefinition, name);
                        methods.add(methodBeanDefinitionHolder);
                    }
                }
            }
            if (methods != null) {
                beanDefinition.getPropertyValues().addPropertyValue("methods", methods);
            }
        }
    }

解析的最终目的是返回 RootBeanDefinition 对象，RootBeanDefinition包含了解析出来的关于bean的所有信息，注意在bean的解析完后其实只是spring将其转化成spring内部的一种抽象的数据对象结构，bean的创建（实例化）是第一次调用 getBean 时创建的。以上是dubbo对配置文件，服务定义的解析过程。后面再写dubbo服务的暴露。

关注我获取视频

•
• 大小: 39.9 KB

• 查看图片附件
